Series NO.: RT460
Terminal Type: Ring Tongue
Terminal Orientation: Straight
Your are here:Home > Products > Terminal & Connector > Crimp Terminals > Crimp Rings > RT460
Series NO.: RT460
Terminal Type: Ring Tongue
Terminal Orientation: Straight
INQUIRE NOW
| Part NO. |
Hole D |
Material | Finish | Wire Range | Thickness |
Packaging Quantity (Reel) |
Certified |
| RT4601701-L-27 | 1.7 | Brass | Unplated | 22-20 | 0.27 | 30K | - |
| RT4602001-27 | 2.0 | Brass | Unplated | 24-22 | 0.27 | 30K | - |
| RT4602002-27 | 2.0 | Brass | Tinned | 24-22 | 0.27 | 30K | - |
| RT4602002-30 | 2.0 | Brass | Tinned | 24-22 | 0.30 | 30K | - |
| RT4602002-40 | 2.0 | Brass | Tinned | 24-22 | 0.40 | 30K | - |
| RT4602004-27 | 2.0 | Brass | Ni-Plated | 24-22 | 0.27 | 30K | - |
| RT4602004-S-27 | 2.0 | Brass | Ni-Plated | 26-24 | 0.27 | 30K | - |
| RT4602012-30 | 2.0 | Stainless Steel | Unplated | 24-22 | 0.27 | 30K | - |
| RT4602202-27 | 2.2 | Brass | Tinned | 24-22 | 0.27 | 30K | - |
| RT4602203-30 | 2.2 | Steel | Ni-Plated | 24-22 | 0.30 | 30K | - |
| RT4602204-30 | 2.2 | Brass | Ni-Plated | 24-22 | 0.30 | 30K | - |
| RT4602501 | 2.5 | Brass | Unplated | 24-22 | 0.27 | 30K | CQC |
| RT4602501-27 | 2.5 | Brass | Unplated | 24-22 | 0.27 | 30K | - |
| RT4602501-L-40 | 2.5 | Brass | Unplated | 22-20 | 0.40 | 30K | - |
| RT4602502-27 | 2.5 | Brass | Tinned | 24-22 | 0.27 | 30K | - |
| RT4602502-L-40 | 2.5 | Brass | Tinned | 22-20 | 0.40 | 30K | - |
| RT4602503-30 | 2.5 | Steel | Ni-Plated | 24-22 | 0.30 | 30K | - |
| RT4602504 | 2.5 | Brass | Ni-Plated | 24-22 | 0.27 | 30K | CQC |
| RT4602504-L-40 | 2.5 | Brass | Ni-Plated | 22-20 | 0.40 | 30K | - |
| RT4602505-30 | 2.5 | Stainless Steel | Unplated | 24-22 | 0.30 | 30K | - |
