Your are here:Home > Products > Terminal & Connector > Crimp Terminals > Crimp Rings > RT500
Series NO.：RT500
Terminal Type:Ring Tongue
Terminal Orientation: Straight
INQUIRE NOW
| Part NO. | Hole D | Material | Finish | Wire Range | Thickness (mm) | Packaging Quantity (Reel) | Certified |
| RT5002501-40 | 25 | Brass | Unplated | 24-20 | 0.4 | 20K | - |
| RT5002501-L-40 | 25 | Brass | Unplated | 22-18 | 0.4 | 15K | - |
| RT5002502-30 | 25 | Brass | Tinned | 24-20 | 0.3 | 20K | - |
| RT5002502-40 | 25 | Brass | Tinned | 24-20 | 0.4 | 20K | - |
| RT5002504-40 | 25 | Brass | Ni-Plated | 24-20 | 0.4 | 20K | - |
| RT5002702-40 | 27 | Brass | Tinned | 24-20 | 0.4 | 20K | - |
| RT5002702-L-40 | 27 | Brass | Tinned | 22-18 | 0.4 | 15K | - |
| RT5002704-L-50 | 27 | Brass | Ni-Plated | 22-18 | 0.5 | 15K | - |
| RT5002802-L-40 | 28 | Brass | Tinned | 22-18 | 0.4 | 15K | - |
| RT5003201-L-40 | 32 | Brass | Unplated | 22-18 | 0.4 | 15K | - |
| RT5003202-40 | 32 | Brass | Tinned | 24-20 | 0.4 | 20K | - |
| RT5003202-L-40 | 32 | Brass | Tinned | 22-18 | 0.4 | 15K | - |
