Series NO.：RT850
Terminal Type:Ring Tongue
Terminal Orientation: Straight
Your are here:Home > Products > Terminal & Connector > Crimp Terminals > Crimp Rings > RT850
Series NO.：RT850
Terminal Type:Ring Tongue
Terminal Orientation: Straight
INQUIRE NOW
| Part NO. |
Hole D (mm) |
Material | Finish |
Wire Range (AWG) |
Thickness (mm) |
Packaging Quantity (Reel) |
Certified |
| RT8504302-40 | 4.3 | Brass | Tinned | 18-16 | 0.40 | 5K | - |
| RT8504302-50 | 4.3 | Brass | Tinned | 18-16 | 0.50 | 5K | - |
| RT8504302-80 | 4.3 | Brass | Tinned | 18-16 | 0.80 | 5K | - |
| RT8504302-L-50 | 4.3 | Brass | Tinned | 16-14 | 0.50 | 5K | - |
| RT8504302-L-80 | 4.3 | Brass | Tinned | 16-14 | 0.80 | 5K | - |
| RT8505302-50 | 5.3 | Brass | Tinned | 18-16 | 0.50 | 5K | - |
| RT8505302-80 | 5.3 | Brass | Tinned | 18-16 | 0.80 | 5K | - |
| RT8505302-L-50 | 5.3 | Brass | Tinned | 16-14 | 0.50 | 5K | - |
| RT8505303-50 | 5.3 | Steel | Ni-Plated | 18-16 | 0.50 | 5K | - |
| RT8505304-50 | 5.3 | Brass | Ni-Plated | 18-16 | 0.50 | 5K | - |
| RT8506302-50 | 6.3 | Brass | Tinned | 18-16 | 0.50 | 5K | - |
| RT8506302-L-50 | 6.3 | Brass | Tinned | 16-14 | 0.50 | 5K | - |
| RT8506303-40 | 6.3 | Steel | Ni-Plated | 18-16 | 0.40 | 5K | - |
