Series No. : NF110
Terminal Type: Receptacle
Terminal Orientation: Flag
Mating Tab width: 2.8mm[.110in]
Your are here:Home > Products > Terminal & Connector > Quick Connect Terminals > 110 Series > NF110
Series No. : NF110
Terminal Type: Receptacle
Terminal Orientation: Flag
Mating Tab width: 2.8mm[.110in]
INQUIRE NOW
| Part NO. |
Mating Tab Thickness (mm) |
Material | Finish |
Wire Range (AWG) |
Thickness (mm) |
Packaging Quantity (Reel) |
Certified |
| NF1100501 | 0.5 | Brass | Unplated | 24-20 | 0.25 | 7K | - |
| NF1100501-F | 0.5 | Brass | Unplated | 24-20 | 0.25 | 7K | - |
| NF1100502 | 0.5 | Brass | Tinned | 24-20 | 0.25 | 7K | - |
| NF1100502-M-30 | 0.5 | Brass | Tinned | 2X22 | 0.3 | 8K | - |
| NF1100801 | 0.8 | Brass | Unplated | 24-20 | 0.25 | 7K | - |
| NF1100802 | 0.8 | Brass | Tinned | 24-20 | 0.25 | 7K | - |
| NF1100802-L-30 | 0.8 | Brass | Tinned | 22-18 | 0.3 | 7K | - |
