Series No.： LS189
Terminal Type： Receptacle
Terminal Orientation： Straight
Mating Tab width： 4.8mm[.187in]
Your are here:Home > Products > Terminal & Connector > Quick Connect Terminals > 187 Series > LS189
Series No.： LS189
Terminal Type： Receptacle
Terminal Orientation： Straight
Mating Tab width： 4.8mm[.187in]
INQUIRE NOW
| Part NO. |
Mating Tab Thickness (mm) |
Material | Finish |
Wire Range (AWG) |
Thickness (mm) |
Packaging Quantity (Reel) |
Certified |
| LS1890502 | 0.5 | Brass | Tinned | 22-18 | 0.3 | 6K | - |
| LS1890503 | 0.5 | Steel | Ni-Plated | 22-18 | 0.3 | 6K | - |
| LS1890802 | 0.8 | Brass | Tinned | 22-18 | 0.3 | 6K | - |
