Series NO.：PG187
Terminal Type: Tab & Receptacle
Terminal Orientation: Piggyback
Mating Tab width：4.8mm【.187in】
Your are here:Home > Products > Terminal & Connector > Quick Connect Terminals > 187 Series > PG187
Series NO.：PG187
Terminal Type: Tab & Receptacle
Terminal Orientation: Piggyback
Mating Tab width：4.8mm【.187in】
INQUIRE NOW
| Part NO. |
Mating Tab Thickness (mm) |
Material | Finish | Wire Range |
Thickness (mm) |
Packaging Quantity (Reel) |
Certified |
| PG1870402 | 0.4 | Brass | Tinned | 22-18 | 0.5 | 1.5K | - |
| PG1870502 | 0.5 | Brass | Tinned | 22-18 | 0.5 | 1.5K | - |
| PG1870502-L | 0.5 | Brass | Tinned | 18-16 | 0.5 | 1.5K | - |
| PG1870503 | 0.5 | Steel | Ni-Plated | 22-18 | 0.5 | 1.5K | - |
| PG1870509 | 0.5 | Carbon steel | Ni-Plated | 22-18 | 0.5 | 1.5K | - |
| PG1870509-L | 0.5 | Carbon steel | Ni-Plated | 18-16 | 0.5 | 1.5K | - |
| PG1870511 | 0.5 | Steel | Tinned | 22-18 | 0.5 | 1.5K | - |
| PG1870801 | 0.8 | Brass | Unplated | 22-18 | 0.5 | 1.5K | - |
| PG1870802 | 0.8 | Brass | Tinned | 22-18 | 0.5 | 1.5K | - |
| PG1870802-L | 0.8 | Brass | Tinned | 22-18 | 0.5 | 1.5K | - |
| PG1870803 | 0.8 | Steel | Ni-Plated | 22-18 | 0.5 | 1.5K | - |
| PG1870803-L | 0.8 | Steel | Ni-Plated | 22-18 | 0.5 | 1.5K | - |
| PG1870811 | 0.8 | Steel | Tinned | 22-18 | 0.5 | 1.5K | - |
