Series No. : SL250
Terminal Type: Receptacle
Terminal Orientation: Straight
Mating Tab width: 6.3mm[.250in]
Your are here:Home > Products > Terminal & Connector > Quick Connect Terminals > 250 Series > SL250
Series No. : SL250
Terminal Type: Receptacle
Terminal Orientation: Straight
Mating Tab width: 6.3mm[.250in]
INQUIRE NOW
| Part NO. |
Mating Tab Thickness (mm) |
Material | Finish |
Wire Range (AWG) |
Thickness (mm) |
Packaging Quantity (Reel) |
Certified |
| SL2500801 | 0.8 | Brass | Unplated | 18-14 | 0.36 | 5K | - |
| SL2500801-F | 0.8 | Brass | Unplated | 18-14 | 0.36 | 5K | - |
| SL2500801-L | 0.8 | Brass | Unplated | 2X18 | 0.36 | 4K | - |
| SL2500802 | 0.8 | Brass | Tinned | 18-14 | 0.36 | 5K | - |
| SL2500802-F | 0.8 | Brass | Tinned | 18-14 | 0.36 | 5K | - |
| SL2500802-L | 0.8 | Brass | Tinned | 2X18 | 0.36 | 4K | - |
| SL2500802-S | 0.8 | Brass | Tinned | 22-18 | 0.36 | 5K | - |
