Series No.： ST250
Terminal Type： Receptacle
Terminal Orientation： Straight
Mating Tab width： 6.3mm[.250in]
Your are here:Home > Products > Terminal & Connector > Quick Connect Terminals > 250 Series > ST250
Series No.： ST250
Terminal Type： Receptacle
Terminal Orientation： Straight
Mating Tab width： 6.3mm[.250in]
INQUIRE NOW
| Part NO. | Mating Tab Thickness | Material | Finish | Wire Range | Thickness | Packaging Quantity (Reel) | Certified |
| ST2500502 | 0.5 | Brass | Tinned | 18-14 | 0.4 | 5K | - |
| ST2500502-XS | 0.5 | Brass | Tinned | 22-18 | 0.4 | 5K | - |
| ST2500503 | 0.5 | Steel | Ni-Plated | 18-14 | 0.4 | 5K | - |
| ST2500801 | 0.8 | Brass | Unplated | 18-14 | 0.4 | 5K | - |
| ST2500801-L-40 | 0.8 | Brass | Unplated | 2X16 | 0.4 | 4K | - |
| ST2500802 | 0.8 | Brass | Tinned | 18-14 | 0.4 | 5K | UL/CQC |
| ST2500802-L-40 | 0.8 | Brass | Tinned | 2X16 | 0.4 | 4K | - |
| ST2500802-M | 0.8 | Brass | Tinned | 2X18 | 0.4 | 5K | - |
| ST2500802-S | 0.8 | Brass | Tinned | 22-18 | 0.4 | 5K | - |
| ST2500802-XS | 0.8 | Brass | Tinned | 22-18 | 0.4 | 5K | - |
| ST2500803 | 0.8 | Steel | Ni-Plated | 18-14 | 0.4 | 5K | UL/CQC |
| ST2500803-M | 0.8 | Steel | Ni-Plated | 2X18 | 0.4 | 5K | - |
| ST2500803-S | 0.8 | Steel | Ni-Plated | 22-18 | 0.4 | 5K | - |
| ST2500804 | 0.8 | Brass | Ni-Plated | 18-14 | 0.4 | 5K | CQC |
| ST2500804-L-40 | 0.8 | Brass | Ni-Plated | 2X16 | 0.4 | 4K | - |
| ST2500805 | 0.8 | Stainless Steel | Unplated | 18-14 | 0.4 | 5K | - |
| ST2500809 | 0.8 | Carbon steel | Ni-Plated | 18-14 | 0.4 | 5K | - |
| ST2500809-L | 0.8 | Carbon steel | Ni-Plated | 2X16 | 0.4 | 4K | - |
| ST2500810 | 0.8 | Carbon steel | Tinned | 18-14 | 0.4 | 5K | - |
| ST2500811 | 0.8 | Steel | Tinned | 18-14 | 0.4 | 5K | - |
